愛普生溫補晶振（TCXO）標準頻率表

作者：愛普生代理江蘇南山發布時間：2020-10-16分類：標準頻率值瀏覽：92次

外部尺寸規格:2.0x1.6x0.73mm

產品代號	型號	額定頻率 [MHz]	頻率溫度特征 f0-TC [1x10-6]	電源電壓Vcc [V]	工作溫度范圍 f_tol [1x10-6]＊1	功耗lcc Max. [mA]	Output Min. [V]
X1G0041310006	TG-5006CJ-15H	16.367667MHz	±0.5/-30 to 85°C	1.8V/2.8V/3V	±2.0ppm	1.5mA	0.8V
X1G0041310013	TG-5006CJ-22L	16.367667MHz	±2.0/-30 to 85°C
X1G0041310007	TG-5006CJ-16H	16.368MHz	±0.5/-30 to 85°C
X1G0041310014	TG-5006CJ-23L	16.368MHz	±2.0/-30 to 85°C
X1G0041310008	TG-5006CJ-17H	16.369MHz	±0.5/-30 to 85°C
X1G0041310015	TG-5006CJ-24L	16.369MHz	±2.0/-30 to 85°C
X1G0041310009	TG-5006CJ-18H	19.2MHz	±0.5/-30 to 85°C
X1G0041310016	TG-5006CJ-25L	19.2MHz	±2.0/-30 to 85°C
X1G0041310010	TG-5006CJ-19H	26MHz	±0.5/-30 to 85°C
X1G0041310017	TG-5006CJ-26L		±2.0/-30 to 85°C
X1G0038410012	TG-5035CJ-12N		±0.5/-30 to 85°C	1.8V/2.8V
X1G0038410010	TG-5035CJ-14N	33.6MHz	±0.5/-30 to 85°C	1.8V	±1.5ppm	2.0mA
X1G0041310011	TG-5006CJ-20H	38.4MHz	±0.5/-30 to 85°C	1.8V/2.8V/3V	±2.0ppm
X1G0041310018	TG-5006CJ-27L	38.4MHz	±2.0/-30 to 85°C	1.8V/2.8V/3V
X1G0038910006	TG-5031CJ-20N	40MHz	±2.0/-30 to 85°C	1.8V/2.8V

外部尺寸規格:2.5x2.0x0.8mm

產品代號	型號	額定頻率 [MHz]	頻率溫度特征 f0-TC [1x10-6]	電源電壓Vcc [V]	工作溫度范圍 f_tol [1x10-6]＊1	功耗lcc Max. [mA]	Output Min. [V]
X1G0042110006	TG-5006CG-15H	16.367667MHz	±0.5/-30 to 85°C	1.8V/2.8V/3V	±2.0ppm	1.5mA	0.8V
X1G0042110013	TG-5006CG-22L	16.367667MHz	±2.0/-30 to 85°C
X1G0042110004	TG-5006CG-13L	16.368MHz	±2.0/-30 to 85°C
X1G0042110007	TG-5006CG-16H	16.368MHz	±0.5/-30 to 85°C
X1G0042110008	TG-5006CG-17H	16.369MHz	±0.5/-30 to 85°C
X1G0042110015	TG-5006CG-24L	16.369MHz	±2.0/-30 to 85°C
X1G0042110009	TG-5006CG-18H	19.2MHz	±0.5/-30 to 85°C
X1G0042110016	TG-5006CG-25L	19.2MHz	±2.0/-30 to 85°C
X1G0042110002	TG-5006CG-11L	26MHz	±2.0/-30 to 85°C
X1G0042110003	TG-5006CG-12H		±0.5/-30 to 85°C
X1G0038510015	TG-5035CG-17N		±0.5/-30 to 85°C	1.8V/2.8V
X1G0042110011	TG-5006CG-20H	38.4MHz	±0.5/-30 to 85°C	1.8V/2.8V/3V		2.0mA
X1G0042110018	TG-5006CG-27L	38.4MHz	±2.0/-30 to 85°C	1.8V/2.8V/3V		2.0mA
